Cushioning and sealing for machinery and control equipment.

PU foam, CR foam, silicone foam and EPDM rubber converted into protective pads, panel gaskets and anti-rattle parts for industrial assemblies.

Discuss Your Project
Email: sales@biscotechcorp.comWhatsApp: 19146424533

Quotes in as little as 30 minutes. Same-day drawings and samples.

Application challenge

Moving equipment needs stable contact points and serviceable seals.

Industrial Equipment applicationIndustrial Equipment

Machine housings and controls face vibration, dust, repeated opening and, in some locations, oil or cleaning-fluid exposure. Pads and gaskets need to match the actual contact load, fluid and temperature rather than a general material label.

BISCOTECH helps select foam and rubber grades, then converts them into die-cut pads, gaskets, adhesive-backed strips and laminated parts based on drawings and assembly requirements.

Typical applications

Sealing and cushioning interfaces in industrial equipment.

Machine Access PanelsCompression gaskets for removable covers and service doors
Control Cabinet InterfacesDust seals around control panels and display surrounds
Sensor and Instrument PadsCushioning at protected mounting and housing interfaces
Cover and Bracket PadsAnti-rattle parts between contacting sheet-metal components
Cable Entry PlatesDie-cut seals for cable-access covers and mounting plates
Equipment Contact PadsProtective pads at rests and stops, with load and compression reviewed

Converting and customization

Delivered in the format your production line needs.

BISCOTECH can select suitable material thicknesses and configure adhesive backing, laminated layers and converted geometry around your drawing and assembly requirements.

Die-cut gaskets and padsSingle-sided or double-sided adhesiveSlit rolls and production widthsMulti-layer thickness stackingPrototype and sample development
Exploded equipment assembly showing silicone foam gaskets around the outer housing, a control board, servo motor and lithium battery

Application example

Example: an industrial access-panel gasket.

Requirement

A machine access panel may need a replaceable gasket that reduces dust entry and panel rattle while allowing routine maintenance.

Proposed approach

Review the panel gap, closure force, vibration and any oil or cleaning-fluid contact, then compare compatible CR, silicone or EPDM grades.

Sample validation

Check compression, maintenance cycles and compatibility with the actual fluids and surfaces before confirming production parts.

Discuss a similar requirement

Related products

Explore cushioning and sealing materials for this application.

PU FoamSoft cushioning, gap filling and anti-rattle pads for protected internal assemblies.View product range CR FoamCushioning and protective pads; select the grade for the expected oil and weather exposure.View product range Silicone FoamResilient sealing and cushioning where temperature range and compression recovery matter.View product range EPDM RubberWeather-resistant gaskets and strips for doors, covers and exposed enclosure interfaces.View product range

FAQ

Common questions about material selection.

Which foam should be used near oil or cleaning fluids?

CR foam may be considered for some oil-exposed cushioning applications, but compatibility depends on the specific fluid, temperature and grade. Identify the exposure and validate samples. PU, silicone and EPDM can be selected for other interfaces according to their individual properties.

Can you provide converted or die-cut parts?

Yes. We support die-cut gaskets and pads, slit rolls, adhesive backing and laminated foam or rubber constructions based on drawings and samples.

What information is needed for material selection and a quote?

Please share a drawing or sample, dimensions, compression gap and load, temperature range, exposure conditions, adhesive surface and estimated quantity. Include any target ingress protection or flame rating; material properties and assembled performance need validation for the chosen grade and design.

Industrial equipment projects

Bring us the requirement behind the part.
